Omron V680-HS63 - Page 98

96
SECTION 7
Specifications and Dimensions
RFID System
User's Manual
SECTION 7
Appendices
 Dimensions
Case material PBT resin
Fill resin Epoxy resin
Mounting Hole Dimensions
(Unit: mm)
32±0.2
32±0.2
Two, M3
4.5
2
5.2
13.2
8
Mounting
reference
surface
16
Two, 3.5-dia.
mounting holes
16
13.2
5.2
8
8
0.2
40±0.1
−0.5
16
16
40±0.1
−0.5
8
