n035 Settings
Setting Description
0 • Setting unit: 0.01 Hz (below 100 Hz), 0.1 Hz (above 100 Hz )
1 • Setting in units of 0.1%: 100.0% at Fmax (n011)
2 to 39 • Setting in units of 1 rpm: (Set number of motor poles in n035)
Display = 120 x frequency value [Hz] / number of motor poles
• Limits: 9999 rpm and rpm x n035 / 120 ≤ 400 Hz
40 to
3999
• Set the display value at 100% of frequency reference (set
value of Fmax (n011)) at the 1st to 4th digits of n035.
The 4th digit of n035, sets the position of decimal point.
The 1st to 3rd digits of n035, sets the display value at 100%
frequency reference (excluding decimal point).
4th digit Position of decimal point
0
1 .
2 .
30.
Example: To display 20.0 at 100% of frequency reference, set
n035 to 1200.
• Limits: max. Display value 999 (3 lower digits of n035)
