50
Simple Data Setting
Digital setting (refer to 5 Operating the Inverter) and potentiometer set-
ting are both possible for simple acceleration/deceleration operation of
the V7AZ.
Digital setting is set at the factory (n004=1). For the model with JVOP-
140 Digital Operator (with potentiometer), factory setting is set by a fre-
quency-setting potentiometer (n004=0).
Following is an example in which the function indicators are used to set
frequency reference, acceleration time, deceleration time, and motor
direction.
To Next Page
