9 Specifications
217
* 1. Based on a standard 4-pole motor for max. applicable motor output.
* 2. Shows deceleration torque for uncoupled motor decelerating from 60 Hz
with the shortest possible deceleration time.
* 3. The operation level becomes approx. 50% of Inverter rated output current
in case of Inverters of 5.5 kW or 7.5 kW.
* 4. The ground fault here is one which occurs in the motor wiring while the
motor is running. A ground fault may not be detected in the following
cases.
• A ground fault with low resistance which occurs in motor cables or ter-
minals.
• A ground fault occurs when the power is turned ON.
* 5. Minimum permissible load: 5 VDC, 10 mA (as reference value)
* 6. For details, refer to “Carrier Frequency Selection (n080)14kHz max” on
page 94.
Status
Indicators
RUN and ALARM provided as standard indicators
Digital Opera-
tor (JVOP-140)
Provided for monitor frequency reference, output frequency, output cur-
rent
Terminals Main circuit: screw terminals
Control circuit: plug-in screw terminal
Wiring Distance
between Inverter and
Motor
100 m (328 ft) or less
*6
Enclosure
Open chassis (IP20, IP00)
*7
, or enclosed wall-mounted NEMA 1
(TYPE 1)
*8
Cooling Method Cooling fan is provided for the following models:
200 V, 0.75 kW or larger Inverters (3-phase)
200 V, 1.5 kW or larger Inverters (single-phase)
Other models are self-cooling.
Ambient Temperature Open chassis (IP20, IP00): −10 to 50 °C (14 to 122 °F)
and enclosed wall-mounted NEMA 1 (TYPE 1): −10 to 40 °C (14 to 105
°F) (not frozen)
Humidity 95% or less (non-condensing)
Storage Temperature
*9
−20 to 60 °C (−4 to 140 °F)
Location Indoor (free from corrosive gases or dust)
Elevation 1,000 m (3,280 ft) or less
Vibration
Up to 9.8 m/s
2
(1G) at 10 to less than 20 Hz,
up to 2 m/s
2
(0.2G) at 20 to 50 Hz
Voltage Class 200 V single-/3-phase
Model
CIMR-
V7AZ
3-phase 20P1 20P2 20P4 20P7 21P5 22P2 24P0 25P5 27P5
Single-phase B0P1 B0P2 B0P4 B0P7 B1P5 B2P2 B4P0 - -
Other Functions
Indications
Environmental Condi-
To Next Page
