Omron VARISPEED V7 User Manual

2 Identifying the Parts
21
V7AZ Inverters with the Covers Removed
Example for 3-phase (200 V Class, 1.5 kW) Inverter
Example for 3-phase (200 V Class, 0.1 kW) Inverter
Frequency-setting Potentiometer
Inverter Operation Status Indicators
Short-circuit
Bar
Ground Terminals
Main Circuit Terminal Block
Control Circuit Terminal Block
Input Polarity
Switch
Ground Terminals
Terminal Resistor Switch for
Communication Circuit
Voltage/Current Change Switch for
Analog Frequency Reference Input
Frequency-setting Potentiometer
Inverter Operation Status Indicators
Short-circuit
Bar
Main Circuit Terminal Block
Control Circuit Terminal Block
Input Polarity
Switch
Terminal Resistor Switch for
Communication Circuit
Voltage/Current Change Switch for
Analog Frequency Reference Input
