238

Third Functions (Constants n080 to n119)

070 0146 Analog Frequency Reference

Filter Time Constant (Voltage

input from Operator)

0.00 to 2.00 s 0.01 s 0.10 s Yes 167

071 0147 Analog Frequency Reference

Gain (Current input from

Operator)

−255% to

255%

1% 100% Yes 167

072 0148 Analog Frequency Reference

Bias (Current input from

Operator)

−100% to

100%

1% 0% Yes 167

073 0149 Analog Frequency Reference

Filter Time Constant (Current

input from Operator)

0.00 to 2.00 s 0.01 s 0.10 s Yes 167

074 014A Pulse Train Frequency

Reference Gain

0 % to 255 % 1 % 100 % Yes -

075 014B Pulse Train Frequency

Reference Bias

-100 % to 100

1 % 0 % Yes -

076 014C Pulse Train Frequency Filter

Time Constant

0.00 to 2.00 s 0.01 s 0.10 s Yes -

077 014D Multi-function Analog Input

Function

0 to 4 - 0 No 121

078 014E Multi-function Analog Input

Signal Selection

0, 1 - 0 No 120

079 014F Frequency Reference Bias

(FBIAS) Value

0 % to 50 % 1 % 10 % No 120

No. Register

No. for

Trans-

mission

Name Setting Range Setting Unit Factory

Setting

Change

during

Opera-

tion

User

Set-

ting

Ref.

Page

080 0150 Carrier Frequency Selection 1 to 4, 7 to 9,

- (Note 4) No 94

081 0151 Momentary Power Loss Ride-

through Method

0 to 2

(Note 9)

-0No79

082 0152 Automatic Retry Attempts 0 to 10 times - 0 No 84

083 0153 Jump Frequency 1 0.00 to 400.0

0.01 Hz

(less than

100 Hz)/0.1

Hz (100 Hz

or more)

0.00 Hz No 84

084 0154 Jump Frequency 2 0.00 to 400.0
