246
• 200 V Class Single-phase
* Sets the value of the motor resistance for one phase.
• 400 V Class 3-phase
* Sets the value of the motor resistance for one phase.
No. Name Unit Factory Setting
- Inverter Capacity kW
0.1 kW 0.25 kW 0.55 kW 1.1 kW 1.5 kW 2.2 kW 4.0 kW
n036 Motor Rated Current A 0.6 1.1 1.9 3.3 6.2 8.5 14.1
n105 Torque Compensation Iron
Loss
W 1.7 3.4 4.2 6.5 11.1 11.8 19
n106 Motor Rated Slip Hz 2.5 2.6 2.9 2.5 2.6 2.9 3.3
n107
Motor Line-to-neutral
Resistance *
Ω 17.99 10.28 4.573 2.575 1.233 0.8 0.385
n108 Motor Leakage Inductance mH 110.4 56.08 42.21 19.07 13.4 9.81 6.34
n110 Motor No-load Current % 72 73 62 55 45 35 32
n159 Motor 2 Mid. Output
Frequency Voltage
V 12.0 12.0 12.0 12.0 12.0 12.0 12.0
n160 Motor 2 Min. Output
Frequency Voltage
V 12.0 12.0 12.0 12.0 12.0 12.0 12.0
No. Name Unit Factory Setting
- Inverter Capacity kW
0.37
kW
0.55
kW
1.1
kW
1.5
kW
2.2
kW
3.0
kW
4.0
kW
5.5
kW
7.5
kW
n036 Motor Rated Current A 0.6 1.0 1.6 3.1 4.2 7.0 7.0 9.8 13.3
n105 Torque Compensation Iron
Loss
W 3.4 4.0 6.1 11.0 11.7 19.3 19.3 28.8 43.9
n106 Motor Rated Slip Hz 2.5 2.7 2.6 2.5 3.0 3.2 3.2 1.5 1.3
n107
Motor Line-to-neutral
Resistance *
Ω 41.97 19.08 11.22 5.044 3.244 1.514 1.514
0.797 0.443
n108 Motor Leakage Inductance mH 224.3 168.8 80.76 53.25 40.03 24.84 24.84
16.87 10.59
n110 Motor No-load Current % 73 63 52 45 35 33 33 26 30
n159 Motor 2 Mid. Output
Frequency Voltage
V 24.0 24.0 24.0 24.0 24.0 24.0 24.0 20.0 20.0
n160 Motor 2 Min. Output
Frequency Voltage
V 24.0 24.0 24.0 24.0 24.0 24.0 24.0 20.0 20.0
