Omron VARISPEED V7 User Manual

4 Wiring
33
400 V Class 3-phase Input Inverters
Note: The wire size is given for copper wire at 75°C (160°F).
Model Terminal Sym-
bols
Screws Tightening
Torque
N•m (lb•in)
Wires
Applicable Size Recommended
Size
Type
mm
2
AWG
mm
2
AWG
CIMR-
V7ΑΖ
40P2
R/L1, S/L2, T/L3,
-, +1, +2, B1, B2,
U/T1, V/T2, W/T3
M4 1.2 to 1.5
(10.65 to
13.31)
2 to 5.5 14 to 10 2 14 600-V vinyl-
sheathed or
equivalent
CIMR-
V7ΑΖ
40P4
R/L1, S/L2, T/L3,
-, +1, +2, B1, B2,
U/T1, V/T2, W/T3
M4 1.2 to 1.5
(10.65 to
13.31)
2 to 5.5 14 to 10 2 14
CIMR-
V7ΑΖ
40P7
R/L1, S/L2, T/L3,
-, +1, +2, B1, B2,
U/T1, V/T2, W/T3
M4 1.2 to 1.5
(10.65 to
13.31)
2 to 5.5 14 to 10 2 14
CIMR-
V7ΑΖ
41P5
R/L1, S/L2, T/L3,
-, +1, +2, B1, B2,
U/T1, V/T2, W/T3
M4 1.2 to 1.5
(10.65 to
13.31)
2 to 5.5 14 to 10 2 14
CIMR-
V7ΑΖ
42P2
R/L1, S/L2, T/L3,
-, +1, +2, B1, B2,
U/T1, V/T2, W/T3
M4 1.2 to 1.5
(10.65 to
13.31)
2 to 5.5 14 to 10 2 14
CIMR-
V7ΑΖ
43P0
R/L1, S/L2, T/L3,
-, +1, +2, B1, B2,
U/T1, V/T2, W/T3
M4 1.2 to 1.5
(10.65 to
13.31)
2 to 5.5 14 to 10 2 14
3.5 12
CIMR-
V7ΑΖ
44P0
R/L1, S/L2, T/L3,
-, +1, +2, B1, B2,
U/T1, V/T2, W/T3
M4 1.2 to 1.5
(10.65 to
13.31)
2 to 5.5 14 to 10 2 14
3.5 12
CIMR-
V7ΑΖ
45P5
R/L1, S/L2, T/L3,
-, +1, +2, B1, B2,
U/T1, V/T2, W/T3
M4 1.4
(12.39)
3.5 to
5.5
12 to 10 5.5 10
CIMR-
V7ΑΖ
47P5
R/L1, S/L2, T/L3,
-, +1, +2, B1, B2,
U/T1, V/T2, W/T3
M5 2.5
(22.13)
5.5 to 8 10 to 8 5.5 10
