54
(n050 to n056) are the same
2. If the following conditions are not satisfied in the V/f pat-
tern setting:
Max. Output Frequency (n011) ≥ Max. Voltage Output
Frequency (n013)
> Mid. Output Frequency
(n014)
≥ Min. Output Frequency
(n016)
Note: Mid. Output Frequency (n014) is also used for
motor 2 settings, n014 has to be lower than n140 and
n147.
For details, refer to Adjusting Torque According to Appli-
cation (V/f Pattern Setting) on page 55.
3. If the following conditions are not satisfied in the jump
frequency settings:
Jump Frequency 3 (n085) ≤ Jump Frequency 2 (n084)
≤ Jump Frequency 1 (n083)
4. If the Frequency Reference Lower Limit (n034) ≤ Fre-
quency Reference Upper Limit (n033)
5. If the Motor Rated Current (n036) ≤ 150% of Inverter
rated current
6. If one of the Acceleration/Deceleration Time settings
(n019 to n022) exceeds 600.0 sec. and it is tried to set
n018 to 1 (Acceleration/Deceleration Time Unit 0.01 sec).
