78
By setting a multi-function input selection (any one of n050 to n056) to
11 (acceleration/deceleration time selection 1) or 27 (acceleration/
deceleration time selection 2), the acceleration/deceleration time is
selected by ON/OFF combinations of acceleration/deceleration time
selection 1 and acceleration/deceleration time selection 2 (terminals S1
to S7).
The combinations of acceleration/deceleration time selection settings
are shown below.
Accleration/
Deceleration
Time Selection 1
Accleration/
Deceleration
Time Selection 2
Acceleration Time Deceleration Time
OFF OFF Acceleration time 1
(n019)
Deceleration time 1
(n020)
ON OFF Acceleration time 2
(n021)
Deceleration time 2
(n022)
OFF ON Acceleration time 3
(n041)
Deceleration time 3
(n042)
ON ON Acceleration time 4
(n043)
Deceleration time 4
(n044)
No. Name Unit Setting Range Factory
Setting
n019 Acceleration Time 1 Depends on
n018 setting.
(See the next
table.)
Depends on
n018 setting.
(See the next
table.)
10.0 s
n020 Deceleration Time 1 10.0 s
n021 Acceleration Time 2 10.0 s
n022 Deceleration Time 2 10.0 s
n041 Acceleration Time 3 10.0 s
n042 Deceleration Time 3 10.0 s
n043 Acceleration Time 4 10.0 s
n044 Deceleration Time 4 10.0 s
