• If the 1st digit “x” of Frequency Offset Selection (n146) is 1 or 2 (fre-
quency offsets enabled), the set values of constants n083 to n085 will
function as frequency offsets.
• In order to activate the offset frequencies 1 to 3 of the Multi-function
Input Selections (n050 to n056) must be programmed to 30, 31 or 33.
Depending on the input status following combinations of the offset
frequencies can be used. Note that the sign specified with “y” is used.
• The enabled offset amount can be monitored on the display of U-12
on the Digital Operator.
Terminal Input Status Final Offset Amount
Offset
Frequency
Input 3
Offset
Frequency
Input 2
Offset
Frequency
Input 1
OFF OFF OFF None
OFF OFF ON n083
OFF ON OFF n084
OFF ON ON n083 + n084
ON OFF OFF n085
ON OFF ON n083 + n085
ON ON OFF n084 + n085
ON ON ON n083 + n084 + n085
Moni-
tor No.
Name Description
U-12 Offset amount 1st digit “x”of n146 = 0: "----" displayed
1st digit “x” of n146 = 1: Display range: −400
to 400.0 Hz
1st digit “x” of n146 = 2: Display range: −
100% to 100.0%
