Omron ZEN Communications Manual

xiii
Conventions Used in This Manual
■ Manual Contents
■ Related Manuals
ZEN Programmable Relay Operation Manual (Z211)
ZEN Support Software Operation Manual (Z184)
Item Description
SECTION 1
Communications Methods
This section briefly describes the supported
communications methods and how to wire
equipment. Refer to this section before set-
ting up equipment.
SECTION 2
CompoWay/F
Communications Protocol
This section describes the protocol for
communications using the CompoWay/F
format.
SECTION 3
Communications Data
This section lists the details of the
communications data in the CompoWay/F
communications protocol.
Appendix ASCII list
This user's manual describes the communications functions of CPU Units with com-
munications. For information on using other functions, refer to the ZEN Programma-
ble Relay Operation Manual.

Omron ZEN Specifications

General

Display	LCD
Mounting Type	DIN Rail
Operating Temperature	-10 to 55°C
Power Supply Voltage	100-240V AC
Output Type	Relay, Transistor
Number of Outputs	4-8
Programming Language	Ladder Logic
