Omron ZEN Communications Manual

SECTION 2 CompoWay/F Communications Protocol
28
Error Occurred
■ Read Time Data
This service reads ZEN time data.
Service Request PDU
Service Response PDU
Note: Each element of the time data (year, month, day of month, hour,
minutes, seconds, and day of week) is expressed as 2-digit BCD
data and converted to ASCI characters.
Response
code
Name Description
1001 Command too long The command is too long.
Time element BCD Time element BCD
Year 00 to
99
Sunday 00
Month 01 to
12
Monday 01
Day of month 01 to
31
Tues day 0 2
Hour 00 to
23
Wednesday 03
Minutes 00 to
59
Thursday 04
Seconds 00 to
59
Friday 05
Saturday 06
MRC SRC
0
22
701
MRC SRC
0
2222 22
701
2 22
Year
Month Hour Min DayDay Sec
