Omron ZEN Communications Manual

SECTION 2 CompoWay/F Communications Protocol
34
2.4 Response Code List
Normal Completion
Error Occurred
Response
code
Name Description
Error
detection
priority
0000 Normal completion No errors were found. None
Response
code
Name Description
Error
detection
priority
0401 Unsupported command The service function for the relevant command is
not supported.
1
1001 Command too long The command is too long. 2
1002 Command too short The command is too short. 3
1101 Area type error Wrong variable type 4
1003 Number of elements/data mis-
match
The amount of data does not match the number
of elements.
5
110B Response too long The response exceeds the communications
buffer size (when the number of elements is
larger than 0002).
6
1100 Parameter error • Bit position is not 00.
• The write data is out of the setting range.
• The command code or related information in
the operation command is wrong.
• The bit address is out of range.
7
3003 Read-only error Variable type “C0” was written to. 8
2203 Operation error Unit error (Memory error occurred, or unused
command was sent.)
9

Omron ZEN Specifications

General

Display	LCD
Mounting Type	DIN Rail
Operating Temperature	-10 to 55°C
Power Supply Voltage	100-240V AC
Output Type	Relay, Transistor
Number of Outputs	4-8
Programming Language	Ladder Logic
