Page #52 background imageLoading...
Page #52 background image
SECTION 3 Communications Data
36
Com Data
3.1 Variable Area (Data Range) List
The following tables list data ranges by variable type. When there is a section reference for a setting
item, refer to that reference for details.
Variable TypeC0 (Read-only)
Address Data name Data range (unit) Remarks Page
0000 Timer PV H'00000000 to H'0000270F (S)
H'00000000 to H'000026E7 (M:S)
H'00000000 to H'000026E7 (H:M)
Timer number specified by left-
most 2 digits of address.
00.00 to 99.99 s
00 min 00 s to 99 min 59 s
00 h 00 min to 99 h 59 min
Note: For twin timers, the PV of
the currently operating
timer is read.
P. 1 8
0001 Timer type, time
unit, and monitor
H'00000000 to H'00420002 (-) Timer number specified by left-
most 2 digits of address.
3rd Digit from Left: Timer Type
0: ON delay
1: OFF delay
2: One-shot pulse
3: Flashing pulse
4: Twin timer
4th Digit from Left: Time Unit
0: 0.01 s
1: M:S
2: H:M
8th Digit from Left: OFF Time
Unit (See note.)
0: 0.01s
1: M:S
2: H:M
Note: Twin timers only.
P. 1 8
0002 Timer bit status H'00000000 to H'0000FFFF (-) Bit 0: T0 Bit 8: T8
Bit 1: T1 Bit 9: T9
Bit 2: T2 Bit 10: Ta
Bit 3: T3 Bit 11: Tb
Bit 4: T4 Bit 12: Tc
Bit 5: T5 Bit 13: Td
Bit 6: T6 Bit 14: Te
Bit 7: T7 Bit 15: Tf
---
0003 Holding timer PV H'00000000 to H'0000270F (S)
H'00000000 to H'000026E7 (M:S)
H'00000000 to H'000026E7 (H:M)
Timer number specified by left-
most 2 digits of address.
00.00 to 99.99 s
00 min 00 s to 99 min 59 s
00 h 00 min to 99 h 59 min
P. 1 8
0004 Holding timer time
unit
H'00000000 to H'00000002 (-) Timer number specified by left-
most 2 digits of address.
0: 0.01 s
1: M:S
2: H:M
P. 1 8
