Omron ZEN Communications Manual

3.1 Variable Area (Data Range) List
37
Com Data
0005 Holding timer bit
status
H'00000000 to H'000000FF (-) Bit 0: #0
Bit 1: #1
Bit 2: #2
Bit 3: #3
Bit 4: #4
Bit 5: #5
Bit 6: #6
Bit 7: #7
---
0006 Counter PV H'00000000 to H'0000270F (-) Counter number specified by left-
most 2 digits of address.
P. 1 8
0007 Counter bit status H'00000000 to H'0000FFFF (-) Bit 0: C0 Bit 8: C8
Bit 1: C1 Bit 9: C9
Bit 2: C2 Bit 10: Ca
Bit 3: C3 Bit 11: Cb
Bit 4: C4 Bit 12: Cc
Bit 5: C5 Bit 13: Cd
Bit 6: C6 Bit 14: Ce
Bit 7: C7 Bit 15: Cf
---
0008 8-digit counter PV H'00000000 to H'05F5E0FF (-) 99999999 max. P.19
0009 8-digit counter
counting speed
H'00000000 to H'00000001 (-) 0: Low speed
1: High speed
---
000A 8-digit counter bit
status
H'00000000 to H'00000001 (-) Bit 0: F0 ---
000B Weekly timer oper-
ating mode
H'00000000 to H'00000002 (-) Timer number specified by left-
most 2 digits of address.
0: Normal
1: Multiple-day
2: Pulse
P. 2 3
000C Weekly timer bit
status
H'00000000 to H'0000FFFF (-) Bit 0: @0 Bit 8: @8
Bit 1: @1 Bit 9: @9
Bit 2: @2 Bit 10: @a
Bit 3: @3 Bit 11: @b
Bit 4: @4 Bit 12: @c
Bit 5: @5 Bit 13: @d
Bit 6: @6 Bit 14: @e
Bit 7: @7 Bit 15: @f
---
000D Analog input value H'00000000 to H'00000069 (V) Analog number specified by left-
most 2 digits of address.
00: I4 (analog input 1)
01: I5 (analog input 2)
00.0 to 10.5 V
P. 1 8
000E Analog comparator
operator
H'00000000 to H'00000021 (-) Comparator number specified by
leftmost 2 digits of address.
P. 1 9
000F Analog comparator
bit status
H'00000000 to H'0000000F (-) Bit 0: A0
Bit 1: A1
Bit 2: A2
Bit 3: A3
---
0010 Comparator opera-
tor
H'00000000 to H'00000029 (-) Comparator number specified by
leftmost 2 digits of address.
P. 1 9
Address Data name Data range (unit) Remarks Page
