Omron ZEN Communications Manual

SECTION 2 CompoWay/F Communications Protocol
24
Example
[STX]010000102C5000000001005623592359
3. Pulse Operation
The time data is as follows (BCD):
Minutes 00 to 59
0 0 5 6 2 3 5 9 2 3 5 9
Start time: 59 minutes
Start time: 23 hours
End day: Saturday (6)
End time: 59 minutes
End time: 23 hours
Always 00.
Start day: Friday (5)
2 1 1 2 2 2 2
+++ + + +
Always 00.
Start day
End day Start time, hour
Start time, minutes
Output time,
minutes
Output time,
seconds
Time data BCD
Sunday 0
Monday 1
Tuesday 2
Wednesday 3
Thursday 4
Friday 5
Saturday 6
No day designated 7
Start time, hour 00 to 23
Start time, minutes 00 to 59
Output time, minutes 00 to 99
Output time, seconds 00 to 59
