11
ZFV
User’s Manual
Introduction
CONTENTS
Introduction
Section 1 Section 2 Section 3 Section 4
Setting output content 70
Customizing Measurement conditions 71
Common items 71
PATTERN/SEARCH, MATCH 72
BRIGHT 73
AREA 74
WIDTH 75
POSITION 76
COUNT 77
CHARA/CHARA 1, CHARA 2 78
Saving the Set Measurement Conditions 82
SECTION 4 APPENDIX 83
Troubleshooting 84
Error Messages and Remedies 85
Q&A 86
Run Mode Display Item List 87
When Gang-mounting Amplifier Units 89
Gang-mounting example 89
Rules of gang-mounting 90
Data route 91
Teaching process when gang-mounting 92
Integrating judgment output 93
Restrictions when gang-mounting old and new amplifier units 94
Specifications and External Dimensions 95
Sensor Head 95
Amplifier Unit 97
Panel Mount Adapters 100
Control Link Unit 101
Extension Cord 102
Version Up Information 103
INDEX 105
Revision History 108
