Section 3 SETUP
Section 3
Setting the System Environment
61
ZFV
User’s Manual
Setting the System Environment
Adjusting the measurement speed
Set the resolution of the input image.
Change the resolution according to the required precision and speed of measurement.
MENU Mode-[SYS1]-[IMAGE RATE]
Selecting the measurement timing
Set the timing that measurement is executed.
MENU Mode-[SYS1]-[MEAS TYPE]
Selecting the teaching mode from an external device
There are two teaching modes from an external device.
MENU Mode-[SYS1]-[TEACH TYPE]
Timing charts p.34
Setting Description
FINE Select this when performing measurement by a high-precision image. Note, how-
ever, that it takes longer to perform measurements.
NORMAL (default value) Standard
HIGH SPEED Select this to perform high-speed measurement. Note, however, that images are
rougher.
Setting Description
TRIG (default value) Synchronous measurement
Measurement is performed in synchronous with the change in state of the external
TRIG signal from OFF to ON.
CONTINUE Continuous measurement
Measurement is repeatedly performed for the duration that the TRIG signal is ON.
Setting Description
STATIONARY (default) Teaching is performed with the workpiece in a stationary state. Input of the exter-
nal trigger input is required for teaching.
MOVING The teaching is performed with the moving workpiece.
Select this teaching mode only when the workpiece cannot be stopped.
Input of the external trigger is required for teaching.
To Next Page
