Section 2 INSTALLATION & CONNECTION
Section 2
Amplifier Unit
25
ZFV
User’s Manual
■ Mounting on a panel
The Panel Mount Adapters (sold separately ZS-XPM1) can be used to mount the
Amplifier Unit on a panel.
Panel Mount Adapters p.100
1. Push out the Amplifier Unit from the rear of
the panel towards the front.
2. Install the small Mount Adapters on the four
holes on the Amplifier Unit.
3. Install the long Mount Adapters on the two
holes on the small Mount Adapter.
Panel
Panel Mount
Adapter
Panel Mount
Adapter
Panel Mount
Adapter
Panel Mount
Adapter
