Section 3 SETUP
Section 3
Executing Teaching
49
ZFV
User’s Manual
6. Press the TEACH key to perform teaching.
When changing the teaching area positioning or size, select [MOVE] or [SIZE] from screen 3 then
adjust accordingly.
Teaching cannot be performed from the MOVE screen or SIZE screen. Set changes with the SET
key then return to screen 6 and perform teaching.
7. Switch to ADJ mode.
8. Measurement starts.
TEACH/SEARCH
1.ITEM 2.MOVE
3.SIZE
ABCDE
TEACH/MOVE
MOVE
ABCDE
TEACH/SIZE
SIZE
ABCDE
[MOVE]
Move the area to the position for teach-
ing then press the SET key.
[SIZE]
Adjust the area size for teaching then
press the SET key.
ADJ
RUNMENU
1.SEARCH OK
99
[ 60]TH
ABCDE
To Next Page
