Omron ZX-LD30V User Manual

Through-beam Sensor Heads: FUN Mode Functions Section 3-8
88
3-8-4 Hysteresis Setting
The hysteresis of the threshold values (hysteresis width) can be set. Any
value can be input directly or the hysteresis can be set automatically.
Refer to 4-5-6 FUN Mode Status Transitions.
If the hysteresis cannot be set, refer to 5-2-4 Unable to Set
Hysteresis.
When the hysteresis is set automatically, the hysteresis width is almost
equal to the resolution.
Z157-E1-01C.book Page 88 Thursday, August 31, 2006 5:13 PM

Omron ZX-LD30V Specifications

General

Type	Laser Displacement Sensor
Ambient humidity	35 to 85% RH (No condensation)
Weight	Approx. 100 g
Linearity	±0.1% of F.S.
Light source	Semiconductor laser
Laser class	Class 2
Measurement Range	±5 mm
Output Type	Analog voltage
Power Supply Voltage	12 to 24 VDC ±10% (ripple: 10% p-p max.)
