Omron ZX-LD30V - PNP Amplifier Unit: ZX-LDA41

I/O Circuit Diagrams Section 1-3
7
1-3-2 PNP Amplifier Unit: ZX-LDA41
Internal circuits
Load
Load
Load
Load
100
Current output
4 to 20 mA
Voltage output
4 V
12 to
24 VD
C
Brown
Blue
White
Green
Gray
12 to 24 VDC
HIGH
output
PASS output
LOW output
GND (0 V)
Pink
Purple
Orange
Red
Black
Shield
Laser OFF input
Zero reset input
Reset input
Linear output
Linear output GND
Current/voltage
output selector
Ti
ming input
Current output: 300 max.
Voltage output: 10 min.
k
