RUN Mode Section 4-3
112
4-3 RUN Mode
4-3-1 Normal Operation
The normal measurement process is performed in RUN Mode.
4-3-2 Changing the Sub-display
The sub-display is changed by pressing the RIGHT and LEFT Keys.
Threshold Display (Default Status)
Set the mode switch to RUN.
The measured value will be displayed
on the main display.
Select the display content for the sub-
display from the thresholds, voltage,
current, incident level, and resolution.
RUN T FUN
The measured value is displayed on the
main display and the threshold value is
displayed on the sub-display.
The decimal point is displayed.
Either the HIGH or LOW threshold
value is selected using the H/L switch.
The incident level is displayed on the
main display in Intensity Mode (incident
level, 9999 max.).
H L
LEFT Key RIGHT Key
Z157-E1-01C.book Page 112 Thursday, August 31, 2006 5:13 PM
