OMS LINEA ESSE S.T.01/3S ED.0 REV.14 03/2017
28
ASSISTANT CONSOLE
The assistant console has three housings, two used for suction tubes, third one can be used for assistant
syringe or curing lamp, and is fitted on an arm that can be:
Linea ESSE as standard has an assistant arm with assistant console swivelling with two joints (arm and assistant
console) as optional can be installed the balance arm, with swivelling movements.
ESSE PLUS as standard has a balance arm, with swivelling movements.
The suction holders are designed for two suction tubes (11 mm Saliva and 16 mm High-Power), third one can
be used for syringe or the curing lamp (a fourth external housing may be provided for additional accessories).
Keyboards of assistant console has the following buttons:
• Bowl rinse (after five switches off automatically)
• Cup filled (can be adjusted)
ASSISTANT KEYBOARD
All the buttons are inside of sealed membrane, to high protection and safety, therefor it is very suitable for
clean and disinfection.
Description of command:
Cup fill
Bowl rinsing on/off.
DANGER
Make sure when LINEA ESSE is driven up and down, the area around the assistant
arm must be clear. The assistant console has a safety device that protect against the
collision with any objects underneath while the chair is driving down.
