OMS LINEA ESSE S.T.01/3S ED.0 REV.14 03/2017
25
FOOT CONTROL
The dental unit is fitted with foot control.
The foot control has been designed to control all instruments feature with a simple movement of the pedal (A).
Pedal (A), placed with a slight pressure towards left (see figure, reference A1), blocks all chair’s movements,
that can be use in case of external dental instrument like laser or electro-surgical device.
Move the pedal towards right to unlock this feature.
Note:
When instrument is selected, it is automatically connected to the foot control, thus all the
other instruments are disable.
Chip-Blower
Pressing pedal (A) of the foot control, the chip-blower is activated.
knobs B and C are used to drive the chair.
