OMS LINEA ESSE S.T.01/3S ED.0 REV.14 03/2017
34
JUCTION FLOOR BOX
The floor box can be built-in (in front of the chair) or separated (in this case it is on the floor near the dental
unit). Inside of the junction box, there are the electric mains connection as well as, inlet water and air, drain,
suction.
Outside of Junction box:
C. General water tap, that controls the inlet water supply to the unit.
A. Main switch electrical switch
B. Fuse
DANGER
The main power switch disconnects the unit from the mains electricity, before
perform any operations, make sure that the power switch is off.
CAUTION
The equipment is equipped with a general water tap. During use, the tap should be
open. At the end of the work day, the tap should be closed, otherwise close the
unit’s general supply tap of the clinic.
