OMS LINEA ESSE S.T.01/3S ED.0 REV.14 03/2017
63
A. Patient chair motors 5AT, 230 Vac
B. Suction 5AT, 230Vac
C. Dental unit 2.5AT, 230Vac
D. Lamp 5AT, 17 Vac, 14.3 Vac
E. Free
F. Backrest motor 5AT, 24Vac (Only for version with floor spittoon unit)
G. Spittoon unit 4AT, 24 Vac
H. General board 6.3AT, 24Vac
Spare fuses supplied by O.M.S. are packed in the accessory box.
DANGER
Fuses should only be replaced by an authorized O.M.S. technician.
