STAND: 17.06.2019 9910_Operation_Manual_STANDCONTROL_C1_Rev1v1_EN Seite 12 von 41
6 Scope of supply and necessary as well as optional accessories
Note: Only listed accessories, approved by OMT, may be used.
Caution: Connecting unapproved components/accessories can result in damage
or malfunctions.
6.1 Delivery scope
The delivery scope contains:
- STAND.CONTROL C1
Other accessories required for operation can be obtained from OMT.
6.2 Necessary accessories
At least the following accessories are required for purpose-conformant use.
- CEE power cable with C8-plug (optionally also PVC/halogen-free)
- Simple hand switch with 2 buttons: STAND.MOVE Mx.0
- Table legs with electric drive
- Motor cable in the same number as the table legs to be connected (length dependent on the
table frame): STAND.CONNECT motor cable (optionally also PVC/halogen-free)
- Screws for fitting on the desktop (see Section 7.2.1) and
Basically, this operating manual assumes a two-motor table with a connected simple hand switch of
the STAND.MOVE M1.0 model. All the descriptions can be carried out with other correctly connected
accessories or any other hand switch at will.
If a description in the operating manual requires another configuration that is explicitly indicated
accordingly.
For large tables with more than two table legs (for example: conference tables), the following are addi-
tionally required:
- Additional STAND.CONTROL C1
- connecting cables: STAND.CONNECT connecting cables
6.3 Optional accessories
For more comfort, additional accessories are available to our customers.
- A mounting plate (if required, see Section 7.2.3), alternatively
- Two controller brackets (not possible with all desktops, see Section 7.2.2)
- Various controller brackets (depending on the desktop)
- Motor cable extension (optionally, also PVC/halogen-free)
- Different comfort hand switches: for example, STAND.MOVE M1.1, STAND.MOVE M1.2
- Collision sensor: STAND.GUARD G1
