STAND: 17.06.2019 9910_Operation_Manual_STANDCONTROL_C1_Rev1v1_EN Seite 34 von 41
13 Acoustic and visual codes
13.1 Acoustic codes
The controller, as soon as it is supplied electric power, can give the user information about the current
system status by means of its integrated relay.
Table 2: Acoustic codes of the controller.
of “click-
clack”
When Status Information
1
Supply of electrical power
(*dependent on configuration)
Normal operation: The system is
functioning without any problems.
Faulty operation: The controller does not
have any firmware: Only 1 click sounds.
1 Up key pressed
Reset: Initialisation movement is
required.
1 Lower blockade detected
Reset: Table has reached the Reset posi-
tion during the initialisation movement.
The
-key can be released.
1 Lower blockade detected
Reset: Initialisation movement has
ended; key continues to be pressed.
Release the key.
2 Set container or shelf stop
Confirmation: The position was
successfully saved.
3 First movement after sensor out
Caution: A previously detected sensor
has been removed. Normal operation
can continue.
3
First movement after sensor
reinserted
Note: A sensor was reconnected after
a previously detected sensor had been
removed. Normal operation can continue.
4 Delete container or shelf stop
Confirmation: The position was
successfully deleted.
6
Container stop or shelf stop too near
in the middle
Warning: An attempt is being made to
set the container stop or shelf stop too
near the middle.
7 Motor cable pulled or missing
Warning: Motor cable absent when con-
necting to the mains, or has been discon-
nected during operation. Connect the
missing motor cable with the controller.
7 Table moves at an angle
Warning: Slanted position of the table
internally has become too big. Carry out
an initialisation movement.
