One Touch H800 - Page 61

FEB-4720 Main Board
CON7 Cash drawer RJ11 connector
PIN No. DESCRIPTION
1
FG (Frame Ground)
2
L1- (Pulse to 0V for 200ms to activate solenoid 1)
3
SW+ (One side of the cash drawer switch)
4
DC +12V (L1+/L2+)(Common to both solenoids)
5
L2- (Pulse to 0V for 200ms to activate solenoid 2)
6
SW- (The other side of the cash drawer switch)
CON3 parallel port LPT1 D-SUB25 connector
PIN No. Description PIN No. Description
1
PRT_STB#
2
PRT_D0
3
PRT_D1
4
PRT_D2
5
PRT_D3
6
PRT_D4
7
PRT_D5
8
PRT_D6
9
PRT_D7
10
PRT_ACK#
11
PRT_BUSY
12
PRT_PE
13
PRT_SLCT
14
PRT_AED#
15
PRT_ERR#
16
PRT_INIT#
17
PRT_SLIN
18
GND
19
GND
20
GND
21
GND
22
GND
23
GND
24
GND
25
GND
CON8 PS/2 mouse connector
PIN No. Description
1
Mouse_DATA
2
NC
3
GND
4
+5V
5
Mouse_CLK
6
NC
56
