13
Front & Rear Panels—Continued
A FRONT L/R, CENTER, SURR/ZONE 3 L/R,
SURR BACK/ZONE 2 L/R, FRONT HIGH L/R,
and FRONT WIDE L/R
These terminal posts are for connecting the front
L/R, center, surround/zone 3 L/R, surround back/
zone 2 L/R, front high L/R, and front wide L/R
speakers.
The FRONT L/R and SURR BACK/ZONE 2 L/R
terminal posts can be used with front speakers and
surround back speakers respectively, or used to bi-
amp the front speakers. See “Bi-amping the Front
Speakers” on page 21”.
The SURR BACK/ZONE 2 L/R terminals can be
used with surround back speakers respectively, or
used to connect the speakers in Zone 2.
See “Connecting Zone 2” on page 116.
The SURR/ZONE 3 L/R terminals can be used with
surround speakers respectively, or used to connect
the speakers in Zone 3.
See “Connecting Zone 3” on page 117.
See pages 18-41 for connection information.
TX-NR807_En.book Page 13 Tuesday, July 28, 2009 12:00 PM
