Onkyo PR-SC886 User Manual

132
Specifications
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
■ Digital Tuner
General
■ Video Input
■ Video Output
■ Audio Inputs
■ Audio Outputs
■ Control Terminal
Specifications and features are subject to change without
notice.
THD (Total Harmonic
Distortion) 0.05% (Power Rated)
Input Sensitivity and
Impedance 200 mV/ 47 kΩ (LINE)
2.5 mV/47 kΩ (PHONO MM)
Output Level and
Impedance 200 mV/ 470 Ω (REC OUT)
Phono Overload 70 mV (MM 1 kHz, 0.5%)
Frequency Response 5 Hz–100 kHz/ +1 dB–3 dB (Direct mode)
Tone Control ±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 110 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
Input Sensitivity/Output
Level and Impedance 1 Vp-p /75 Ω
(Component and S-Video Y)
0.7 Vp-p /75 Ω (Component Pb/Cb,Pr/Cr)
0.28 Vp-p /75 Ω (S-Video C)
1 Vp-p /75 Ω (Composite)
Component Video
Frequency Response 5 Hz – 100 MHz, –3 dB
Tuning Frequency Range
North American: 87.5 MHz– 107.9 MHz
European and Asian: 87.50 MHz– 108.00 MHz, RDS
Tuning Frequency Range
North American: 530 kHz–1710 kHz
European and Asian: 522 kHz–1611 kHz
Preset Channel 40
North American: XM, SIRIUS, HD RADIO
Power Supply
North American: AC 120 V, 60 Hz
European and Asian: AC 220-240 V, 50 Hz/60 Hz
Power Consumption
North American: 1.1 A
European and Asian: 85 W
Dimensions
(W
× H × D) 435 × 194 × 444.5 mm
17-1/8" × 7-5/8" × 17-1/2"
Weight 13.5 kg
29.8 lbs.
HDMI IN 1, IN 2, IN 3, IN 4
Component IN 1 (DVD), IN 2, IN 3
S-Video DVD, VCR/DVR, CBL/SAT, GAME/TV,
AUX 1, AUX 2
Composite DVD, VCR/DVR, CBL/SAT, GAME/TV,
AUX 1, AUX 2
HDMI MAIN OUT, SUB OUT
Component MONITOR OUT 1,
MONITOR OUT 2/ZONE 2 OUT
S-Video VCR/DVR OUT, MONITOR OUT
Composite VCR/DVR OUT, MONITOR OUT,
ZONE 2 OUT
Digital Inputs OPTICAL: 2 (Rear), 1 (Front)
COAXIAL: 3 (Rear)
Analog Inputs MULTI CH (FRONT, CENTER,
SUBWOOFER, SURR, SURR BACK),
DVD, VCR/DVR, CBL/SAT, GAME/TV,
AUX 1, TAPE, CD, PHONO, AUX 2
Balance Inputs BALANCE L, BALANCE R
Multichannel Inputs 7.1
Digital Output OPTICAL: 1 (Rear)
Analog Outputs VCR/DVR OUT, TAPE OUT, PRE OUT
(FRONT, CENTER, SUBWOOFER,
SURR, SURR BACK)
Z2 PREOUT, Z3 PREOUT
Balance Pre Outputs FL, FR, C, SL, SR, SBL, SBR, SW
Multichannel Pre
Outputs 7
Subwoofer Pre Outputs 1
Phones 1
MIC Yes
Ether 1(e-control)
RS232 1
IR Input/Output 2/1
12 V Trigger Out
3
