105
Zone 2—Continued
This section explains how to turn Zone 2 on and off, how
to select an input source for Zone 2, and how to adjust
the volume for Zone 2.
Controlling Zone 2 from the AV receiver
Note:
When Zone 2 is turned off, the output from the 12V
TRIGGER OUT ZONE 2 goes low (0 volts).
Controlling Zone 2 with the Remote
Controller
Note:
To control Zone 2, you must press the remote control-
ler’s [ZONE2] button first.
The ZONE2 button turns red while Zone 2 is on.
Using Zone 2
1
To turn on Zone 2 and select an
input source, press the [ZONE 2]
button followed by an input
selector button within 8 seconds.
Zone 2 turns on, the ZONE 2 indicator
lights up.
Tip :
The 12V TRIGGER OUT ZONE 2
goes high (+12 V).
To select AM or FM press the
[TUNER] input selector and the
[ZONE 2] button repeatedly. You can
also select SIRIUS (North American
models).
To select the same source as that of the
main room, press the [ZONE 2] button
twice. “Zone 2 Selector: Source”
appears on the display.
2
To turn off Zone 2, press the
[ZONE 2] button.
The ZONE 2 indicator flashes.
Press the [OFF] button.
The zone is turned off, and the ZONE 2
indicator goes off.
OFF
Input selector buttons
ZONE 2
ZONE 2 indicator
1
Press the [ZONE2] button, then
point the remote controller at the
AV receiver and press the [ON]
button.
Tip :
The 12V TRIGGER OUT ZONE 2
goes high (+12 V).
2
To select an input source for
Zone 2, press the [ZONE2]
button, followed by an INPUT
SELECTOR button.
To select AM or FM press the
[TUNER]
INPUT SELECTOR
and the
[ZONE2] button repeatedly. You can
also select SIRIUS (North American
models).
3
To turn off Zone 2, press the
[ZONE2] button, followed by the
[STANDBY] button.
INPUT
SELECTOR
ON
ZONE2
STANDBY
TX-SR707_En.book Page 105 Tuesday, July 28, 2009 1:03 PM
