Onkyo TX-SR707

36
Connecting the AV receiver—Continued
• With connection , you can play and record or listen in Zone 2.
• To connect the recorder digitally for playback, use connections and , or and .
Connecting a Cassette, CDR, MiniDisc, or DAT Recorder
Step 1:
Choose a connection that matches the recorder ( , or ), and then make the connection.
a b c
a
a b a c
Connection AV receiver Signal flow Cassette, CDR, MD, or DAT recorder
TV/TAPE IN L/R
TV/TAPE OUT L/R
⇐
⇒
Analog audio L/R output
Analog audio L/R input
DIGITAL COAXIAL IN 3 (CBL/SAT) ⇐ Digital coaxial output
DIGITAL OPTICAL IN 1 (GAME) ⇐ Digital optical output
a
b
c
c
AUDIO
IN
LR
L
R
IN
TV/TAPE
AUDIO
OUT
LR
L
R
TV/TAPE
COAXIAL
OUT
OPTICAL
OUT
COAXIAL
OPTICAL
IN 3
(CBL/SAT)
IN 1
(GAME)
a
a
b
Cassette, CDR, MD, or
DAT recorder
When you use connection or
, you need to assign the digital
audio input (see page 46).
b
c
