DS-E Series（1~6KVA）User’s Manual
15
3.4.2 Selection of Input and Output Power Cord Diameter
For the selection of conducting wire sectional area for UPS AC input and output
cable and battery cable, please refer to Table 3-2 for corresponding
recommended values, and choose values upwards.
Table 3-2 Recommended Sectional Flow of Cable Sectional Area of UPS
Sectional Area (mm
2
) Ampacity
(A)
1 1.5 2.5 4 6 10 16 25
Rubber
(25°C)
8 12 20 28 42 70 96 125
Plastic
(25°C)
6 9 15 20 30 50 64 100
3.5 Cable Connection
To connect UPS cable only after confirming that all air switches on UPS are in
disconnection condition, and the equipment is properly installed.
3.5.1 DS1000E Series
All input and output connection methods of DS1000E series are shown in Fig.
3-2.
