Opticon M-10 Specification Manual

M-10
Specifications Manual
5
4. Detailed View
Figure 1: Detailed View of M-10
No Name Description
1
Scan Window
A window to which codes are presented.
Trigger Switch
A trigger switch to read codes for use as a handheld scanner
1. Press the trigger switch once, then a green single aiming line lights up.
2. Position the single aiming line over the code and press the trigger switch
again to start reading.
2
Status LED
The operating statuses are indicated by blue color different brightness.
Light blue:
Indicates the scanner being in standby state.
Bright blue:
indicates a successful read of codes
3
Buzzer Holes
Holes through where a sound comes out from a built-in buzzer.
4
Stand
Stands to adjust the angle of the scanner. Adjustable range:
Forward:60°Backward: 15°
1
3
4
2

Opticon M-10 Specifications

General

Brand	Opticon
Model	M-10
Category	Scanner
Language	English
