M-10
Specifications Manual
2
3. Basic Specifications
Item Specification Note
CPU 32-bit RISC
SDRAM 256 M bits (2 M × 4 Banks × 32 Bits )
Control
Section
Flash ROM 16 M bits (1 M × 16 Bits) Flash Memory
RS-232C 300 bps ~ 115200 bps
Default :9600bps
Interf
ace
USB USB2.0 Full Speed 12 Mbps (HID/COM)
Scanning method WVGA CMOS Area sensor (Mono)
Frame rate: 60 fps
Scanning light source 2 Red LEDs
LED Reflector
Aiming and auto trigger
activation light source
1 Green LED
Effective pixels 0.36 million pixels (H: 752 x V: 480)
Field of view
(Vertical x Horizontal)
0 mm
50 mm
100 mm
150 mm
: 48 x 31 mm
: 85 x 54 mm
:122 x 78 mm
:165 x 105 mm
Typical Value
Optical Section
View angle
Horizontal
Vertical
: about 40.6°
: about 26.4°
1D
UPC-A, UPC-E, UPC-E1, UPC-A Add-on ,
UPC-E Add-on, EAN-13, EAN-8, EAN-13
Add-on/EAN-8 Add-on, JAN-8, JAN-13, Code
39, Tri-Optic, NW-7, Industrial 2 of 5,
Interleaved 2 of 5, Code 93, Code 128,
GS1-128, S-Code, MSI/Plessey, UK/Plessey,
TELEPEN, Matrix 2 of 5, IATA, Code 11,
Symbologies
Postal
Intelligent Mail Barcode, POSTNET, PLANET,
Netherlands KIX Code, UK Postal (Royal
mail), Australian Postal, Japanese Postal,
Korean Postal Authority code, Chinese Post
Matrix 2 of 5
Minimum resolution Code 39 : 0.127 mm
Curvature
Radius ≧ 20 mm (12-digit 13mil UPC/EAN)
Wide barcode
Possible to read: Code 39 with 100 mm width
and resolution 0.2mm (DOF: 95 mm)
Motion tolerance
Possible to read: 13mil 100%UPC/EAN moving
at 2 m/s (DOF: 65 mm)
Resolution 0.127 (5mil) 35 ~ 60
Code 39
Resolution 0.254 (10mil) 0 ~ 140
Code 128 Resolution 0.2 (7.9mil ) 10 ~ 120
Supported 1D Symbologies
Depth of field
(mm)
100%UPC/EAN Resolution 0.33 (13mil) 0 ~ 170
PCS 0.9
Symbologies
GS1 DataBar, GS1 DataBar Limited, GS1
DataBar Expanded, GS1 DataBar Composite,
GS1-128 Composite, EAN Composite , UPC
Composite
GS1 DataBar
Minimum resolution (mm)
GS1 DataBar
Composite Code
: 0.169 (6.7mil)
: 0.169 (6.7mil)
PCS 0.9
