Opticon M-10 Specification Manual

M-10
Specifications Manual
3
Item Specification Note
Symbologies
PDF417, MicroPDF417, Codablock F, QR
Code , Micro QR Code, DataMatrix (ECC 0 -
140 / ECC 200), MaxiCode, Aztec Code,
Chinese Sensible Code
Disable Code 128
when Codablock F is
enabled.
Minimum resolution (mm)
PDF417
QR Code
DataMatrix
: 0.169 (6.7mil)
: 0.169 (6.7mil)
: 0.212 (8.4mil)
Resolution (0.169) 25 ~ 70
PDF417
Resolution (0.254) 0 ~ 120
Resolution (0.212) 35 ~ 55
QR Code
Resolution (0.381) 0 ~ 120
Supported 2D Symbologies
Depth of field
(mm)
DataMatrix Resolution (0.254) 30 ~ 85
Pitch : ±50°
Skew : ±50°
Scan angle
Tilt : 360°
PCS 0.9
Common
Minimum PCS 0.3 or more
MRD: 32% or more
Image data format Windows Bitmap, JPEG
Shades of gray 1024, 256, 16, 2
Range of output image Select top/bottom (row) and left/right (column)
Resolution of output image Full,1/2, 1/4
Interface of output image RS-232C, USB-COM
Black spot may appear
on image, however, it
does not affect the
scanning performance.
USB-COM
( Full speed )
About 3 sec
Imager
Baud rate
RS-232C
(Baud rate: 115.2 kbps)
About 40 sec
Resolution: Full
Range of operating voltage
4.5 ~ 5.5 V: USB
5.4 ~ 6.6 V: RS-232C (D-Sub9pin)
(external power supply )
RS-232C (D-Sub9pin)
External power supply:
Dedicated AC adapter
6.0 V ±5%
Reading Peak 420 mA (Max)
Reading Ave. 250 mA (Typ)
Standby 150 mA (Typ)
Auto trigger sleep 110 mA (Typ)
Power
Current consumption
(USB)
Non Operation 48 mA (Typ)
USB 5.0V
Operating 0 ~ 40°C
AC adapter: 0 ~ 40°C
Temperature
Storage -40 ~ 70°C
Operating 5 ~ 90% (no condensing, no frost)
Humidity
Storage 5 ~ 90% (no condensing, no frost)
Fluorescent 10,000 lx or less
Ambient light
immunity
Sunlight 100,000 lx or less
Vibration
10 Hz ~ 100 Hz, acceleration of 19.6 m/s2, 60
minutes per cycle, repeat once in each X, Y
and Z-direction
Drop
Drop 3 times, at each 5 faces (right, left, front,
back and top), from a height of 1.5 m onto a
concrete surface.
* Excluding the part
where the interface
cable is attached
Environmental Specifications
Dust & Water Proof Grade IEC/EN 60529 protection level :IP 52

Opticon M-10 Specifications

General

Brand	Opticon
Model	M-10
Category	Scanner
Language	English
