Version 2.0.2 2014-11-04Page 74 Original operating instructions
B17Pro | B23Pro | B26Pro | B33ProGB
9Annex
9.1 Copyright
This document is copyright. All derived rights are also reserved, especially those of translation,
re-printing, use of figures, broadcast, reproduction by photo-mechanical or similar means and
recording in data processing systems, neither partial nor total.
Subject to technical changes without notice.
9.2 Terminology/Glossary
9.3 Change information manual
Term Explanation
Drill sleeve Fixed hollow shaft in which the drilling spindle turns
Drilling spindle Shaft activated by the motor
Quick-action drill chuck Drill chuck can be fixed by hand.
Drill chuck Drill bit chuck
Drill drift Tool to release the bit or the drill chuck from the drill spindle
Taper mandrel Cone of the drill or of the drill chuck
Tool Milling cutter, drill bit, countersink, etc.
Workpiece Workpiece to be turned drilled or machined.
Drilling table Supporting surface, clamping surface
Drill head upper part of the drilling machine
Star wheel Manual operation for the drill feed
Chapter Short note new version no.
EC declaration changed standard 1.2.9
All Merging of standard + Vario 2.0
3 Image switch of drill chuck protection 2.0.1
1 + 4 Type plates + speed tables 2.0.2
