808D
Page 149
ISO Mode
Brief instruction 808D Milling
Operating and Programming — Milling
Basic Theory
N10 T1D1M6 ; contour milling tool
N20 G54G90G40G17
N30 M3S2000M8
N40 G0Z25
N50 X0Y-70
N55 CYCLE72( "SUB_PART_4", 50, 0, 2, -5, 2.5,
0.1, 0.1, 200, 200, 111, 41, 2, 20, 200, 2, 20)
N60 T2D1M6 ; quill, drill center hole
N70 M3S2500M8
N80 MCALL CYCLE82( 50, 0, 2, 0, 2, 0)
N90 CYCLE802( 111111111, 111111111, 40, -
40, 40, 40, -40, 40,
-40, -40, ,)
N100 MCALL
N110 T3D1M6 ; quill; deep hole drilling
N120 M3S2500M8
N130 MCALL CYCLE83( 50, 0, 2,
-20, ,-5, ,3, 0.5, 1, 1, 1, 3, 3, 0, ,0)
N140 CYCLE802( 111111111, 111111111, 40, -
40, 40, 40, -40, 40,
-40, -40, ,)
N150 MCALL
N160 G0G40G90Z60
N170 M09M05
N180 M30
; SUB_PART_4.SPF
G17 G90 DIAMOF
G0 X0 Y-50
G1 X-50 RND=10
Y50 RND=10
X50 RND=10
Y-50 RND=10
X0
M2;/* end of contour */
Standard Siemens programming.
Machining the same workpiece as
described above (can be compared with the
ISO code).
