OPTIMUM
MASCHINEN - GERMANY
Technical data
Version 1.0 dated 2015-05-27 Page 20 Original operating instructions
F3GB
2 Technical data
The following information represents the dimensions and indications of weight and the manu-
facturer‘s approved machine data.
2.1 Electrical connection
2.2 Milling spindle
2.3 Lubricant/coolant system
2.4 Compressed air
Total connection 3 x 400V ~ 50Hz 2.5 KW
performance spindle drive 1.5 KW
Torque 10 Nm
Speed 200 - 4000 min
-1
Spindle seat ISO 30 / BT 30 x 45°
Power of the coolant/lubricant pumps [W] 95
Tank capacity [l] 50
Connection [MPa] 0.8 (8 bar)
Air consumption 0.01 - 0.015 m
3
/ h at 0.8 MPa
Recommended compressed air quality ISO 8573.1 class 2
Compressed air consumer • Tool clamp / unclamp
Compressed air service unit Drainage filters 40 µm
max. pressure 1.5 MPa
Housing Polycarbonate
Recommended oil lubrica-
tor for compressed air
ISO VG32
Quantity of oil Lubricator for
compressed air
90ml
Drainage manually
Compressed air connec-
tion thread
3/8"
