4 Operation
4.1 Control and indicating elements
Pos. Designation Pos. Designation
1 Selector lever speed adjustment 2 Change wheel and feed table
3 Control panel 4 Selector lever feed gear
5 Chip sump 6 Lathe chuck protection
7 Chip guard shield 8
Machine lighting (hidden behind the chip
shield)
10 Tailstock 11
Digital Position Indicator DPA 21
(TM4010D only)
12 Control panel lathe saddle 14 Rotational direction control lever
15 Lead screw 16 Feed rod
1
2
3
4
6
5
10
11
14
12
7
16
15
8
