COMPACT version 5.2.002 ENG
8
Modular audio matrix
with IP connection
COMPACT
4ETH
R + D Department
DIPSWITCH
NUMBER
* A/B DRY CONTACT
WITH 3K3 RESISTOR
A/B DRY CONTACT
WITHOUT 3K3
RESISTOR
“A” CONTACT
REFERENCED TO
GROUND
OUTPUT
CONTACT 1
1
OFF
ON
OFF
2
OFF
OFF
OFF
3
OFF
OFF
ON
OUTPUT
CONTACT 2
4
OFF
ON
OFF
5
OFF
OFF
OFF
6
OFF
OFF
ON
OUTPUT
CONTACT 3
7
OFF
ON
OFF
8
OFF
OFF
OFF
9
OFF
OFF
ON
SW2 DIPSWITCH.
JUNCTION BETWEEN POWER
SUPPLY NEGATIVE AND CHASSIS
* JOINED
DIPSWITCH 1 → ON*
DIPSWICTH 2 → ON*
SEPARATED
DIPSWITCH 1 → OFF
DIPSWICTH 2 → OFF
* FACTORY SETTINGS
* FACTORY SETTINGS
Figure 7
OUTPUT CONTACTS CONFIGURATION
WARNING: Disconnect the power
supply of the equipment before
removing and handling the A495MP
control module.
DIPSWITCH S1.
CONFIGURATION OF THE OUTPUT CONTACTS
Remove the A495MP
control module
