Optoma HD21 - Disassemble Lamp Cover Module; Disassemble Lamp Module

HD20/HD200X/HD2200/HD20LV/HD21/HD23
Condential 2-2
2-3 Disassemble Lamp
Module
1. Unfasten 2 screws (as red circle) on the
Lamp Module.
2. Take off the Lamp Module.
2-2 Disassemble Lamp
Cover Module
1. Unfasten 2 screws (as red circle) on the
Lamp Cover.
2. Disassemble the Lamp Cover Module.
