Optoma HD21 - Disassemble LVPS Module

2-16 Disassemble LVPS
Module
1. Unscrew 6 screws (as red circle).
2. Disassemble the LVPS Module.
3. Unplug 4 connectors (as blue square).
Condential 2-14
2. Unplug 2 connectors (as blue square).
3. Unscrew 4 screws (as red circle) to
disassemble the Lamp Driver Module.
HD20/HD200X/HD2200/HD20LV
