HD20/HD200X/HD2200/HD20LV/HD21/HD23
Condential 2-16
2-18 Disassemble Bottom
Cover Shielding
1. Tear off 2 mylar (as blue square).
2. Unscrew 2 screw (as red circle) to
disassemble the Bottom Cover Shielding.
