Optoma HD21 - EDID Upgrade Equipment

HD20/HD200X/HD2200/HD20LV/HD21/HD23
Condential
6-2
6-2 Equipment Needed
Software
- EDID .exe
- EDID le(*.ini)
Hardware
- HD20 unit
- HDMI(M) to DVI(F) Adapter P/N:42.82B13G001
- DVI to DVI cable P/N:42.83N06G001
- RS-232 9 pin cable ( Male to Female) P/N:42.83C07G001
- EDID Fixture (JP3 must be closed) P/N:80.00001.001
- PC
- VGA to VGA cable P/N:42.87305G102
- Power adapter for xture P/N:47.57803G001
- Power cord P/N:42.53506G002
Note: - The EDID Upgrade procedure for HD20/HD200X/HD2200/HD20LV/HD21/HD23 is the
same, we take HD20 for example here.
