HD20/HD200X/HD2200/HD20LV/HD21/HD23
Condential 2-17
2-20 Disassemble I/O Cover
1. Remove the I/O Cover.
2-19 Disassemble Security
Bar Cap
1. Unscrew 1 screw (as red cricle) to
disassemble the Security Bar Cap.
