HD20/HD200X/HD2200/HD20LV/HD21/HD23
Item P/N Description Parts Supply
70.8EG36GR01 ASSY ENGINE MODULE FOR HD20 (SERVICE) V
70.8HW03GR01 ASSY ENGINE MODULE FOR HD20LV (SERVICE) V
70.8NJ10GR01 ASSY ENGINE MODULE FOR 8NJ (SERVICE) V
1 70.8EG16G001 ASSY ENGINE BASE HD20
70.8EG32GR01 ASSY ROD MODULE FOR HD20 (SERVICE) V
2 70.8EG11G001 ASSY ROD MODULE HD20
3 70.8CP15G001 ASSY RELAY MODULE Z15
70.8EG37GR01
ASSY COLOR WHEEL MODULE FOR
HD20(SERVICE)
V
70.8HW04GR01 ASSY COLOR WHEEL MODULE FOR
HD20LV(SERVICE)
V
70.8NJ11GR01
ASSY COLOR WHEEL MODULE
R62G64B54R62G64B54 8NJ(SERVICE)
V
4 70.8EG12G001 ASSY COLOR WHEEL MODULE HD20
5 70.8AH02G001 ASSY ENGINE BOTTOM COVER M409WX
6 23.8CV01G001 PROJECTION LENS YM40
7 61.8EG10G001 DMD HEATSINK AL6063 HD20
8 52.87319G001 DMD THERMAL PAD 18*13*0.5t
9 61.80J10G001 DMD LIGHT MASK 739 SUS301
10 61.88611G001 DMD SCREW Ivy10X
11 51.00210G001 DMD SCREW WASHER A39
12 48.8EG01G001
DMD 0.65” 1080P 2xLVDS DC2 TYPE A 1910-6127
WITH SINGLE DDP3021 TI
V
13 11.009F0G007
CNNT F 203P FOR 720P LGA DMD SOCKET
PE020323-03040-10;FOXCO
14 85.00826G080 HEX SCREW M2.6*H8*L4,BRASS
15 61.8AS03G001 CONDENSER LIGHT STOP SUS304 0.3t 1609WX
16 23.8AH20G001 CONDENSER1 FOR A15W
17 23.8AH20G002 CONDENSER 2 FOR A15W
18 51.89F02G001 DMD INSULATION PC A15
19 61.8AH08G001 DMD PLATE AL A6061 M409WX
20 61.8AH05G001 ROD COVER SUS301 0.25t 3/4H M409WX
21 61.88N12G001 ROD SPRING SUS301,X15
22 52.80J01G001 DMD ANTIDUST RUBBER 739 SILICONE RUBBER
23 80.8EG02G001 PCBA DMD BOARD FOR HD20 V
24 85.1A526G060 SCREW PAN MECH M2.6*6 Ni NYLOK
25 61.8AH13G001 DMD HEATSINK SPRING SUS304 M409WX
26 61.85927G001 DMD SHOULDER SCREW SB21
27 85.WA321G040 SCREW PAN TAP M1.7*4 BLACK
28 41.83F16G001 GASKET W*10 H*10 L*40
